II Basic Operation
7 Inserting/Removing Analyzer
- 28 -
7 Inserting/Removing Analyzer
Press the ANALYZER IN/OUT key to insert and remove
the analyzer.
LED INDICATION:
IN OUT
Green Orange
Note:
If the analyzer is not connected, the LED will not light up.
8 Opening/Closing Shutter
Press the SHUTTER A key to open and close the shutter
allocated to SHUTTER A.
Press the SHUTTER B key to open and close the shutter
allocated to SHUTTER B.
LED INDICATION:
OPEN CLOSE
Green Orange
Note:
If the allocation for the SHUTTER A key and the SHUTTER B key is set to “OFF,” the LED will not light up.
For details on shutter allocation, see section I-4 (Setting Shutter Key Function).
9 Operating Dia-Illumination Lamp (12V100W lamp only)
(1) Turning Remote Control Operation ON/OFF
Remote control operation refers to operating the
dia-illumination lamp of the microscope from the remote
control pad.
Press the DIA LAMP REMOTE key to turn remote control
operation ON or OFF.
LED INDICATION:
Operation ON Operation OFF
Green Orange
Note:
When EXTERNAL switch of the dia-illumination lamp power supply is OFF, you cannot operate the lamp on the
remote control pad nor turn the remote control operation ON or OFF. The LED will not light up.
To Next Page
