Nikon T-RCP User Manual

III Additional Functions
1 Interlocking Objective and Condenser Module Selection
- 31 -
III
III
Additional Functions
1 Interlocking Objective and Condenser Module Selection
If combinations of objectives and condenser modules are set, then when an objective is selected, the condenser
module corresponding to the objective is automatically selected.
1
Press the MODE key, and the SETTING MENU screen will
appear on the LCD.
Select “Combination (OBJ>Condenser)” using the S key
or the T key and then press the [

] key.
ＳＥＴＴＩＮＧ ＭＥＮＵ
Ｏｂｊｅｃｔｉｖｅ
Ｃｏｎｄｅｎｓｅｒ
Ｆｉｌｔｅｒ
Ｅｘｃｉｔｅｒ
Ｂａｒｒｉｅｒ
Ｃｏｍｂｉｎａｔｉｏｎ（Ｏｂｊ．＞Ｃｏｎｄｅｎｓｅｒ）
Ｃｏｍｂｉｎａｔｉｏｎ（Ｆｉｌｔｅｒ＞ＥＸ／ＢＡ）
Ｍｏｒｅ
2
Select the address in the condenser module changeover
to interlock with Address 1 of the revolving nosepiece
using the PREV or NEXT key.
ＣＯＭＢＩＮＡＴＩＯＮ（ＯＢＪ．＞ＣＯＮＤＥＮＳＥＲ）
Ｏｂｊｅｃｔｉｖｅ Ｃｏｎｄｅｎｓｅｒ
１．Ｐ Ｆｌｕｏｒ ＤＬ ４ｘ ［
２］：ＰｈＬ
２．Ｐ Ｆｌｕｏｒ ＤＬ １０ｘ ［－］：―――――
３．Ｐ Ｆｌｕｏｒ ＥＬＷＤ ＤＭ ２０ｘ ［－］：―――――
４．Ｐ Ｆｌｕｏｒ ＥＬＷＤ ＤＭ ４０ｘ ［－］：―――――
５．Ｐ Ｆｌｕｏｒ ＥＬＷＤ ＤＬＬ ６０ｘ ［－］：―――――
６．Ｐ Ｆｌｕｏｒ ＤＬＬ １００ｘ［－］：―――――
3
Move to the next address of the revolving nosepiece using
the
S key or theT key and repeat step 2 above.
ＣＯＭＢＩＮＡＴＩＯＮ（ＯＢＪ．＞ＣＯＮＤＥＮＳＥＲ）
Ｏｂｊｅｃｔｉｖｅ Ｃｏｎｄｅｎｓｅｒ
１．Ｐ Ｆｌｕｏｒ ＤＬ ４ｘ ［２］：ＰｈＬ
２．Ｐ Ｆｌｕｏｒ ＤＬ １０ｘ ［
－］：―――――
３．Ｐ Ｆｌｕｏｒ ＥＬＷＤ ＤＭ ２０ｘ ［－］：―――――
４．Ｐ Ｆｌｕｏｒ ＥＬＷＤ ＤＭ ４０ｘ ［－］：―――――
５．Ｐ Ｆｌｕｏｒ ＥＬＷＤ ＤＬＬ ６０ｘ ［－］：―――――
６．Ｐ Ｆｌｕｏｒ ＤＬＬ １００ｘ［－］：―――――
4
Press the MODE key to end the setting and to return to the
OPERATION screen.
Note:
“-” indicates that the address is not interlocked.
Unless both the revolving nosepiece and the condenser module changeover are connected, you cannot set the
combinations.
