NSM–3/3D
Product Variants
PAMS Technical Documentation
Page 8
Issue 4 02/2002
 Nokia Corporation
Assembly Parts of NSM–3DX
CIRCUIT REF./
ITEM Q’TY CODE DESCRIPTION VALUE, TYPE
I001 9458046 A–cover assy DMC03233
I002 9790470 Keymat module, basic DMC03232
I002 alt 9790482 Keymat module Bopomofo
I002 alt 9790483 Keymat module Stroke
I003 9490575 LCD module assy
I004 5407805 Connector elastomer Ag/Si
I005 4700127 RTC battery
I006 5140067 Speaker + spring 103±3 dB
I007 0201682 RM7LD radio module
I008 6 6150029 Screw M1.6x4.5 flat head 0.8mm (Use 17 Ncm torque)
I009 9490244 B–cover assy DMC03273
I010 5409095 DC & HS connector
I011 6800041 Vibra motor assy
I012 5409155 SIM connector
I013 5140175 Microphone+holder+springs
I014 5219019 Voulume switch up/down
I015 9790397 Voulume key DMD05078
I016 5409093 Battery connector 4 pole
I017 9560085 SIM spring DMD05211
I018 9458047 Battery art cover assy (incl. logo) NSM–3D
I020 9460327 A–cover fixing left DMD05127
I021 9460328 A–cover fixing right DMD05128
I022 9660147 Twin Rip DMD06257
I023 0660196 Antenna EGSM/PCN
I024 9510545 Battery latch spring DMD05129
I025 9451601 Battery latch DMD05083
