NSM–3/3D
Service Software Instructions
PAMS Technical Documentation
Page 22
Issue 4 02/2002
Nokia Mobile Phones Ltd.
Custom Dialog boxes
All custom dialog boxes will contain the predefined buttons as defined be-
low in the section –
Buttons.
However, it is recognized that features may
require additional button types, but the addition of these non–standard
buttons should be carefully considered to minimize any inconsistencies
between implementations.
The buttons will be positioned down the right–hand side of the dialog
boxes. The default action will be OK, except where that default action
could result in an irretrievable failure.
All tuning dialogs that contain tuning results, will display the old tuned
data read from the phone before the tuning was performed, as well as the
newly tuned data.
List boxes will be used to display lists of data, such as tuning data, test
results etc.
The use of Radio buttons should be limited and carefully considered. The
use of radio buttons defines the number of possible choices available to
the user, which may be acceptable for one project, but not for another.
Buttons
All buttons must be the Microsoft style of buttons.
In general, the default button will be the action button, the Close button or
the Yes button, but this will depend on the context of the dialog box that
the button is associated with.
(action) button:
Accepts and validates entered settings and values and closes
the dialog. If the values have not been changed, then no action
will be taken. The status bar will reflect the status. The user
should only be queried, if the settings or values accepted will
over–write data that CAN NOT be reproduced.
A greyed OK button indicates that settings selected by the user
are not acceptable.
Close button:
Closes the current dialog box. Does not send or store anything
and closes the dialog. The Close button is only used for dia-
logs that do not set or change any data.
Cancel button (Esc):
Cancel operation. Does not send or store anything and closes
the dialog box.
A greyed Cancel button indicates that it is not possible to quit
from this dialog box.
Yes button (ALT+Y or Y):
