NSM–3/3D
Service Software Instructions
PAMS Technical Documentation
Page 13
Issue 4 02/2002
Nokia Mobile Phones Ltd.
Menu Bar
The Service Software package will have two menu bar configurations.
The first, is an abbreviated version that contains the minimum number of
menus that allows package configurations when a phone is NOT con-
nected. The second is described below:
The menu bar MUST only contain the follow menus for the Service Soft-
ware package when a phone is connected:
• P
roduct*
• C
onfigure*
• T
uning
• Te
sting
• S
oftware
• Dealer
• V
iew
• H
elp*
* – always displayed, even if no phone is connected.
A menu is broken down into sections that are indicated with menu sepa-
rators. Each sections identifies a logical difference from itself and other
sections, i.e. between transmitter and receiver. Any items that are re-
quired to be added to a menu lists will be added on the bottom of the ap-
propriate menu section list. If a new item is to be added which is common
to two or more phone types, then that menu item will become a common
menu item.
The menu lists will use the Microsoft [...] symbol after an item name to in-
dicate that selecting that item will NOT initiate an operation immediately,
i.e. a dialog box will be displayed for the user to select options or type in
data and press the OK button before the operation is performed.
Product
The Product menu contains at least the following menu items:
• N
ew Ctrl+R
• Open...
• C
lose
• I
nitialize
• Normal Mode F5
• L
ocal Mode Shift+F5
•Faultlog
• Activate Faultlog... F9
• Edit Faultlog...
• Ex
it Alt+F4
