Nokia NSM–3 User Manual

NSM–3/3D
Service Software Instructions
PAMS Technical Documentation
Page 11
Issue 4 02/2002
 Nokia Mobile Phones Ltd.
Cancel button (ESC)
The Dialog box is closed and application is started, but the
Faultlog feature is disabled.
Help button (F1)
Activates the Windows Help application and displays context
sensitive Help.
Main Window
Title bar
The title bar is located at the top of the window.
A title bar contains the following elements:
• Application Control–menu button
• Maximise button
• Minimise button
• Name of the application
• Restore button
The properties of these elements and their usage is described in Ref 3–
Microsoft Windows Version 3.1 Users Guide chapter one (Windows Ba-
sics) and chapter two (Application Basics).
Menu bar
The
menu bar is below the title bar and contains all available menu selec-
tions. The menu bar is a dynamic element and is dependent on the
dongle type fitted, and whether a phone is connected.
Underlined characters in menu names and options indicates that the
menu selection can be done by pressing Alt + underlined character . Op-
tions can also be selected by activating menu bar with
Alt – key ( or F10
key ) and using arrow–keys to highlight the desired menu. In that case,
selection is done by pressing Enter .
Menus can also be selected by using the mouse as described in Ref
3–Microsoft Windows Version 3.1 Users Guide
Status bar
The
status bar is displayed at the bottom of the Service Software main
window. The status bar contains information about the menu selections
and events.
The left area of the status bar describes the actions of menu items as the
user uses the arrow keys to navigate through menus.
