NSM–3/3D
Service Software Instructions
PAMS Technical Documentation
Page 57
Issue 4 02/2002
Nokia Mobile Phones Ltd.
Start Up Self–tests... command
Activation Status Bar Text
Alt, S,S Open MCU start Up self–tests dialog box.
Function is used for changing the state of the EEPROM selectable tests
in MCU Start Up Self–tests dialog.
Dialog mode: modal
MCU Start Up Self–tests dialog includes following items:
Tests list box (ALT+T):
When the dialog is opened, the previous values will be read
from the MCU EEPROM and shown on the list box.
Status group:
When the radio button On is selected, the test will be run every
time when automatic start up self–tests are activated (e.g. in
power up).
Save button (ENTER)
Selections are accepted and saved to EEPROM. A power up
routine is made to the phone.
Cancel button (ESC)
Selections are ignored and control is returned back to main
menu.
Selectable Start–Up self tests:
PPM Validity
A/D Converter
