Nokia NSM–3 User Manual

NSM–3/3D
General Information
PAMS Technical Documentation
Page 6
Issue 3 11/2000
 Nokia Mobile Phones Ltd.
Technical Specifications
General Specifications of Transceiver NSM–3/3D
Parameter Unit
Cellular system GSM900 and GSM1800
RX frequency band EGSM: 925 ... 935 MHz
GSM900 935 ... 960 MHz
GSM1800 1805 ... 1880 MHz
TX frequency band EGSM 880 ... 890 MHz
GSM900 890 ... 915 MHz
GSM1800 1710 ... 1785 MHz
Output power GSM900 * +5 ...+33 dBm / 3.2 mW ... 2 W
GSM1800 +0 ...+30 dBm / 1.0 mW ... 1 W
Duplex spacing GSM900 * 45 MHzGSM1800 95 MHz
Number of RF channels EGSM 50
GSM900 124
GSM1800 374
Channel spacing 200 kHz
Number of TX power levels GSM900 * 15 GSM1800 16
Sensitivity, static channel GSM900: –102 dBm
GSM1800: –100 dBm
Frequency error, static channel < 0.1 ppm
RMS phase error < 5.0
o
Peak phase error < 20.0
o
*) applies also to EGSM
