Nokia NSM–3 User Manual

NSM–3/3D
General Information
PAMS Technical Documentation
Page 5
Issue 3 11/2000
 Nokia Mobile Phones Ltd.
Product and Module List
Unit/type: Product
code:
Transceiver NSM–3/3D See Product
Variants
Standard Battery BLB–2 650 mAh Li–ion 0670246
AC Travel Charger ACP–7E (EUR) 207–253 Vac 0675144
AC Travel Charger ACP–7U (US) 108–132 Vac 0675143
AC Travel Charger ACP–7C (US) 198–242 Vac 0675158
AC Travel Charger ACP–7X (UK) 207–253 Vac 0675145
AC Travel Charger ACP–7H (UK) 180–220 Vac 0675146
AC Travel Charger ACP–7A (AUS) 216–264 Vac 0675148
Performance Travel Charger ACP–8E (EUR)
90–264 Vac
0675195
Performance Travel Charger ACP–8K (Korea)
90–264 Vac
0675199
Performance Travel Charger ACP–8X (UK)
90–264 Vac
0675197
Performance Travel Charger ACP–8U (US)
90–264 Vac
0675196
Performance Travel Charger ACP–8C (China)
90–264 Vac
0675211
Performance Travel Charger ACP–8A (Australia)
90–264 Vac
0675214
Headset HDC–5 0694059
Loopset LPS–3 0630244
Pocket Clip SKB–2 0720218
Swivel Mount HHS–12 0620054
Desk Stand DCV–1B 0675220
HF Microphone HFM–8 0690016
Plug&Play HF Cigarette Lighter Charger PPH–1 0675182
Cigarette Lighter Charger LCH–8 0675231
Cigarette Lighter Charger LCH–9 0675120
