NSM–3/3D
Service Software Instructions
PAMS Technical Documentation
Page 29
Issue 4 02/2002
 Nokia Mobile Phones Ltd.
RX Calibration... command
Activation Status Bar Text
Alt, T, R Open RX Calibration dialog box
Starts RX calibration.
Next automatic selections are made when this tuning function is acti-
vated:
• Phone is set to local mode
• Update RF information window
The measurement is started automatically when RX calibration is entered.
The measurement is done in five steps:
1. The user is requested to put signal generator to high input level (read
from .INI file).
2. Measurement with high input level is executed
3. The user is requested to put signal generator to low input level (read
from .INI file).
4. Measurement with low input level is executed
5. The RX Calibration dialog will be updated when previous steps are
done.
