Nokia NSM–3 User Manual

NSM–3/3D
Service Software Instructions
PAMS Technical Documentation
Page 33
Issue 4 02/2002
 Nokia Mobile Phones Ltd.
Tx Power... command
Activation Status Bar Text
Alt, T, X Open TX Power Tuning dialog box
Starts TX power tuning.
When the user has PKD–1 dongle in place tuning is started automatically
with EEPROM values.
Tuning values are loaded from program’s internal memory.
The next automatic selections are made when this tuning function is acti-
vated:
the BASE power level is selected
Operation mode = TX pulsed
The TX Power Tuning dialog will be activated automatically after value
selection.
NOTE: Make sure you are working with GSM900 band. First tune power
levels 5, 15 and 19. Then Calculate the other levels and save the values.
After this switch to PCN band and do the tuning to levels 0, 11 and 15.
Then Calculate the other levels and save the values.
GSM900 TX Power Tuning dialog:
GSM1800 TX Power Tuning dialog:
