Oki MB760 Service Manual

45641001TH Rev.1
4-20 /
Oki Data CONFIDENTIAL
4.4.11 AdjustmentofthecapacityandimagequalityofSlimPDF
ThecompressionqualityortheresolutionisadjustedtoreducethelecapacityofaSlimPDFor
improveitsquality.
<AdjustmentMode(05)>
Code Itemtobeadjusted Remarks
9104 Compressionqualityof
SlimPDF background
processing
Thesmallerthevalue,thelessthelecapacityandthe
lowertheimagequalitybecomes.Thelargerthevalue,
the greater the file capacity and the higher the image
qualitybecomes.
Acceptable values: 0 to 10 (Default: 5)
9107 Resolution of SlimPDF
background processing
Thesmallerthevalue,thelessthelecapacityandthe
lowertheimagequalitybecomes.Thelargerthevalue,
the greater the file capacity and the higher the image
qualitybecomes.
0: 75dpi
1: 100dpi
2: 150dpi
3: 200dpi
Acceptable values: 0 to 3 (Default: 1)
<Procedure>
(1) Whilepressing[0]and[5]simultaneously,turnthepowerON.
(2) Keyinthecodestobeadjustedandpressthe[START]button.
(3) Keyintheadjustmentvalue.(Tocorrectavalueoncekeyedin,pressthe[CLEAR]button.)
(4) Pressthe[OK]or[INTERRUPT]buttontostorethevalueinmemory.
→
Theequipment
goes back to the ready state.
(5) Lettheequipmentrestart.AcquiretheSlimPDFleandcheckit.
(6) Ifthedesiredimagequalityhasnotbeenattained,repeatstep(1)to(5).
4.4.12 Surroundingvoidamountadjustment
Thevoidamountaroundthenetworkscannedimageisadjusted.
Innetworkscanning,sincethevoidamountisverysmallinstoredimages,ashadowmay
appear around the scanned image due to the subtle difference in the original sizes. This shadow
canbeeliminatedbyadjustingthesettingvalue.
The setting value is applied to all resolutions and color modes.
<AdjustmentMode(05)>
Code Itemtobeadjusted Remarks
7489 Surrounding void amount
adjustment
Whenthevalueincreases,theblankareaaroundthe
scannedimagebecomeswider,andthedataonthe
image decrease.
Acceptable values: 0 to 255 (Default: 0)
Thesettingvalue“1”isequalto1dotwith600dpi.(The
value“24”isequaltoapprox.1mm.)
<Procedure>
The procedure is the same as that of

P.4-15“4.4.2Densityadjustment”.
