2 Models and External Dimensions
2 - 120
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
The following are the dimensions of External Dynamic Brake Resistors.
R88A-RR550
2-4-7 Dimensions of External Dynamic Brake Resistors
R88A-DBR300
2-10
20
28
2-R3
17.8
200 min.
FG
342
382
2-10.4
362
20
58.8
28
2-6 dia.
197
t 1.6
235
250
60
4.5
80
40
500
t2.5
2-4.5 dia.
