1 - 29
1 Features and System Configuration
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
1-5 Applicable Standards
1
1-5-1 EU Directives
1-5 Applicable Standards
This section describes applicable standards.
The 1S-series Servomotors, Servo Drives, and Footprint-type Noise Filters conform to the following
standards.
Note To conform to EMC Directives, install the Servo Drive and Servomotor under the conditions described in
4-3 Wiring Conforming to EMC Directives on page 4-47.
The Servo Drives and Servomotors comply with EN 61800-5-1 as long as the following installation
conditions (a) and (b) are met.
(a) Use the Servo Drive in pollution degree 2 or 1 environment as specified in IEC 60664-1.
Example: Installation inside an IP54 control panel.
(b) Connect a fuse or a breaker
• The Servo Drives with its capacity 3 kW or less
Be sure to connect a fuse or an equivalent that the fusing time is shorter, which complies with
IEC 60269-1 CLASS gG, between the power supply and noise filter.
Select a fuse that satisfies the maximum current rating of the following table.
1-5-1 EU Directives
EU Directives Product Applicable standards
EMC Directive Servo Drives EN61800-3 second environment,
C3 Category
(EN 61326-3-1
*1
Functional Safety)
*1. The applicable standard of following models is EN61000-6-7.
Applicable models: R88D-1SN55ï‚£-ECT, R88D-1SN75ï‚£-ECT,
R88D-1SN150ï‚£-ECT
Low Voltage Directive Servo Drives EN 61800-5-1
Servomotors EN 60034-1/-5
Footprint-type Noise
Filters
EN 60939-2
Machinery Directive Servo Drives EN ISO 13849-1 (Cat.3)
EN 61508
EN 62061
EN 61800-5-2
Servo Drive model
Maximum current
rating
R88D-1SN01L-ECT 16 A
R88D-1SN02L-ECT 16 A
R88D-1SN04L-ECT 16 A
R88D-1SN01H-ECT 16 A
R88D-1SN02H-ECT 16 A
R88D-1SN04H-ECT 16 A
R88D-1SN08H-ECT 16 A
R88D-1SN10H-ECT 16 A
R88D-1SN15H-ECT 40 A
R88D-1SN20H-ECT 40 A
R88D-1SN30H-ECT 40 A
R88D-1SN06F-ECT 20 A
To Next Page
