1 Features and System Configuration

1 - 20

AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)

The shield clamp part names are given below.

*1. It comes with a cable.

*2. Do not cut cable ties.

*3. It is equipped with a cable.

1-3-5 Shield Clamp Part Names

Shield clamp

plate

Cable tie

Shield clamp

blacket
