5 - 15

5 EtherCAT Communications

AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)

5-7 Emergency Messages

When an error or warning occurs in a 1S-series Servo Drive, an emergency message is sent to the

master through SDO communications. An emergency message is not sent for a communications error.

You can select whether or not to send emergency messages in Diagnosis History (10F3 hex).

When the power supply is turned ON, Diagnosis History – Flags (10F3-05 hex) is set to 0 (not

notify).

To send emergency messages, set the least significant bit of Diagnosis History – Flags (10F3-05 hex)

to 1 every time the power is turned ON.

An emergency message consists of 8-byte data.

Note For details on errors and warnings of the Servo Drive, refer to Section 12 Troubleshooting.

Byte 0 1 2 3 4 5 6 7

Con-

tents

Emergency Error Code

*1. Error codes (FF00 to FFFF hex) in the manufacturer-specific area are used. Byte 0 is fixed to FF hex, and

byte 1 shows the main code of an error number or warning number.

Error Register

(object 1001

hex)

Manufacturer-specific Error Field

*2. Byte 3 is not used. An error code is shown in bytes 4 to 7. For details on error event codes, refer to A-4 Sys-

mac Error Status Codes on page A-100.
