Omron R88D-1SN10F-ECT User Manual

2 Models and External Dimensions
2 - 130
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
The following are the dimensions of Footprint-type Noise Filters.
2-4-9 Noise Filter Dimensions
R88A-FI1S103/ -FI1S202
R88A-FI1S105/ -FI1S203
2-M4
2-R2.25 notch
230
±2.0
(10)198
±2.0
22
±1.0
222
±1.0
20
±0.5
20
±0.5
40
±1.0
45
±1.0
(4.5)
4
±0.5
170
±0.5
42
±0.5
2-4.5 dia.
28
±0.5
DOWN
UP
300
±10.0
DOWN
UP
55
±1.0
35
±0.5
3-M4
240
±2.0
4
±0.5
52
±0.5
170
±0.5
232
±1.0
(4.5)
35
±0.5
43
±0.5
28
±0.5
(10)208
±2.0
22
±1.0
45
±1.0
300
±10.0
2-R2.25 notch
2-4.5 dia.
