4 Configuration and Wiring
4 - 14
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
Obey the following conditions when installing.
• Clearance with peripheral equipment: 50 mm min.
• Wire length: 3 m max.
Obey the following conditions along with the general installation conditions when installing.
• Installation Direction: Install the terminal block side of the unit in the gravity direction (downward).
Obey the following conditions along with the general installation conditions when installing.
• Installation Direction: Install the connector side of the unit in the gravity direction (downward).
• Tightening torque: 3.0 N·m
Specifications for attached connectors are shown below. Follow the specified length of stripped wire.
For a wiring procedure, refer to CNE of R88D-1SN150H-ECT of Procedure for Wiring Terminal Block
and Procedure for Mounting Shield Clamp to Servo Drive on page 4-34.
• Connector model: R88A-CN101E (832-1102/037-000 manufactured by WAGO)
• Length of stripped wire: 19±1 mm
4-1-4 External Regeneration Resistor and External Regeneration
Resistance Unit Installation Conditions
General Installation Conditions
External Regeneration Resistance Unit with Fan Installation Condi-
tions
External Regeneration Resistance Unit without Fan Installation Con-
ditions
To Next Page
