124
Using Output Signals (n057, n058, n059)
The functions of multi-function output terminals MA, MB, P1 and P2
can be changed as necessary by setting constants n057, n058, and n059.
• Terminal MA and MB functions: Set in n057
• Terminal P1 function: Set in n058
• Terminal P2 function: Set in n059
Setting Name Description Ref.
page
0 Fault Closed when Inverter fault occurs. -
1 Operating Closed when either FWD/REV Run
Command is input or voltage is output
from the Inverter.
-
2 Frequency agree Closed when the set frequency agrees
with Inverter output frequency.
125
3 Zero speed Closed when Inverter output frequency
is less than minimum output frequency.
-
4 Frequency detection 1 Output frequency ≥ Frequency Detec-
tion Level (n095)
82
5 Frequency detection 2 Output frequency ≤ Frequency Detec-
tion Level (n095)
82
6 Overtorque detection,
NO contact output
-81
7 Overtorque detection,
NC contact output
-81
8 Undertorque detected,
NO contact output
-185
9 Undertorque detected,
NC contact output
-185
10 Minor fault Closed when an alarm has been de-
tected.
-
11 Base blocked Closed when the Inverter output is
OFF.
-
12 Operating mode Closed when LOCAL is selected for the
LOCAL/REMOTE selection.
-
13 Inverter operation
ready
Closed when an Inverter fault is not de-
tected, and operation is ready.
-
14 Fault retry Closed during fault retries. -
15 UV Closed when undervoltage is detected. -
