* 7. 0P1 to 3P7 are of IP20. Be sure to remove the top and bottom covers
when Inverter 5P5 or 7P5 of open chassis mounting type is used.
* 8. NEMA 1 of 0P1 to 3P7 is optional, while NEMA 1 of 5P5 and 7P5 is pro-
vided as standard.
* 9. Temperature during shipping (for short period).
Standard Specifications (400 V Class)
Voltage Class 400 V 3-phase
Model
CIMR-
V7AZ
3-phase 40P2 40P4 40P7 41P5 42P2 43P0 44P0 45P5 47P5
Single-phase---------
Max. Applicable Motor Output
kW
*1
0.37 0.55 1.1 1.5 2.2 3.0 4.0 5.5 7.5
Inverter Capacity (kVA) 0.9 1.4 2.6 3.7 4.2 5.5 7.0 11 14
Rated Output Current
(A)
1.2 1.8 3.4 4.8 5.5 7.2 9.2 14.8 18
Max. Output Voltage
(V)
3-phase, 380 to 460 V (proportional to input voltage)
Max. Output
Frequency (Hz)
400 Hz (Programmable)
Rated Input Voltage
and Frequency
3-phase, 380 to 460 V, 50/60 Hz
Allowable Voltage
Fluctuation
−15 to +10%
Allowable Frequency
Fluctuation
±5%
Output CharacteristicsPower Supply
