52
6 Programming Features
Factory settings of the constants are shaded in the tables.After wiring is
complete, be sure to make the following settings before operation.
Hardware
Make the following settings before the Inverter is turned ON.
Software (Constant)
Item Ref.
page
Sequence input signal (S1 to S7) polarity selection 226
Voltage reference / current reference input selection of con-
trol circuit terminal FR
126
Item Ref.
page
Environment
setting
Constant Selection / Initialization (n001) 53
Control Mode Selection (n002) 59
Run Command Selection (n003) 63
Frequency Reference Selection (n004) 64
Stopping Method Selection (n005) 106
Basic
characteristics
and frequency ref-
erence setting
V/f pattern setting (n011 to n017) 55
Acceleration Time 1 (n019),
Deceleration Time 1 (n020)
77
Frequency Reference 1 to 8
(n024 to n031)
74
Motor protection Motor Rated Current (n036) 136
Electric Thermal Motor Protection
Selection (n037)
136
Countermeasure
for noise and leak-
age current
Carrier Frequency Reference (n080) 94
Using an optional
braking resistor
Stall Prevention during Deceleration
(n092)
134
To Next Page
