FUN (Function) Mode Section 4-5
132
4-5-6 FUN Mode Status Transitions
The status transitions in the FUN mode are shown in the following chart.
Timer time
setting
Timer mode
Hold
Hysteresis
Number of samples
to average
2- sensor
operation
Settings
initialization
Special
No hold
Peak hold
Bottom hold
Sample hold
Peak-to-peak
Self-peak
Self-bottom
ON-delay
One-shot
No timer
OFF-delay
Timer time can be set only when OFF-delay,
ON-delay, or 1-shot timer is set.
Timer time setting item is added after the
timer mode setting.
No 2-sensor operation
A − B mode
A + B mode
No special setting
display
Settings-related
Displays-related
Other
All displayed
Hold down the ENT
Ke y for 3 seconds.
3 seconds later
Selected special
items
Scaling function
Hysteresis width is normally
changed by direct input.
Automatic hysteresis width setting
can also be performed by pressing
the ENT Key for 3 seconds.
Press the ENT and RIGHT
Keys to move to the self-trigger
level setting.
Numeric values are confirmed
by pressing the UP and
DOWN Keys.
Confirmed by pressing the ENT
Key.
Can be selected only
when two Sensors
are connected.
Displayed bars light one-by-one from the left.
All of them light after 3 seconds to indicate OK
.
1,024 times
512 times
4 times
2 times
1 time
4,096 times
2,048 times
256 times
128 times
64 times
32 times
16 times
8 times
For details,
Press the ENT and RIGHT Keys to
move to the timer time setting.
Auto-scale
Can be selected only
for Through-beam
Sensor.
Numeric values are confirmed
by pressing the UP and
DOWN Keys.
Confirmed by pressing the ENT
Key.
Self-trigger level
see 4-5-7.
For details, see 4-5-9.
For details, see 4-5-11.
For details, see 4-5-12.
For details, see 4-5-13.
