Procedures for Reflective Sensor Heads Section 2-3
22
2-3 Procedures for Reflective Sensor Heads
2-3-1 Positioning and Setting Threshold Values
Manual Setting
3-4-2 Inputting Threshold Values Directly
Automatic Setting
Workpiece surface positioning:
Position Teaching in 3-4-1 Teaching
Unknown size workpiece judgement:
Two-point Teaching in 3-4-1 Teaching
Judging workpiece with uneven surfaces, warped workpieces, or mov-
ing workpieces:
Automatic Teaching in 3-4-1 Teaching
2-3-2 Setting Various Functions
Changing the display value:
3-5-1 Scaling
Changing response speed or increasing resolution:
3-5-2 Number of Samples to Average
Changing positioning accuracy when operating and releasing:
3-5-3 Hysteresis Setting
Holding value during measurement:
3-5-4 Hold Functions
Using OFF-delay timer:
3-5-5 Timer
Operation requiring two Sensor Heads:
3-5-6 Two-sensor Operation
Resetting default status:
3-5-7 Initializing Settings
Changing the output current or voltage range:
Special Functions (Set)
3-5-8 Monitor Focus Function
Detecting the optical level:
Special Functions (Set)
3-5-9 Intensity Mode
