Omron ZX-LDA11 User Manual

Ratings/Specifications Section 6-1
153
6-1-3 Amplifier Units
Item ZX-LDA11 ZX-LDA41
Measurement period
150
µS
Possible average count
settings
(See note 1.)
1, 2, 4, 8, 16, 32, 64, 128, 256, 512, 1,024, 2,048, or 4,096
Temperature
characteristic
When connected to a Reflective Sensor Head: 0.01% FS/
°C
When connected to a Through-beam Sensor Head: 0.1% FS/
°C
Linear output
(See note 3.)
Current output: 4 to 20 mA/FS, Max. load resistance: 300
Ω
Voltage output: ±4 V (± 5 V, 1 to 5 V, See note 4.), Output
impedance: 100
Ω
Judgement outputs
(3 outputs: HIGH/
PA S S/ LOW )
NPN open-collector outputs,
30 VDC, 50 mA max.
Residual voltage: 1.2 V max.
PNP open-collector outputs,
30 VDC, 50 mA max.
Residual voltage: 2 V max.
Laser OFF input ON: Short-circuited with 0-V
terminal or 1.5 V or less
OFF: Open (leakage current:
0.1 mA max.)
ON: Supply voltage short-
circuited or within supply
voltage 1.5 V
OFF: Open (leakage current:
0.1 mA max.)
Zero reset input
Timing input
Functions
 Measured value
display
 Set value/light
level/resolution
display
 Scaling
 Display reverse
 Display OFF mode
 ECO mode
 Number of display
digit changes
 Sample hold
 Peak hold
 Bottom hold
 Peak-to-peak hold
 Self-peak hold
 Self-bottom hold
 Intensity Mode
(See note 5.)
 Auto-scale
(See note 6.)
 Zero reset
 Initial reset
 ON-delay timer
 OFF-delay timer
 One-shot timer
 Differentiation/
Sensitivity
adjustement
 Keep/clamp
switch
 Direct threshold
value setting
 Position teaching
 2-point teaching
 Automatic teaching
 Hysteresis width
setting
 Timing inputs
 Reset input
 Monitor focus
 Setting for non-
measurement
 (A−B) calculations
(See note 2.)
 (A+B) calculations
(See note 2.)
 Mutual interference
(See note 2.)
 Laser deterioration
detection
 Key lock
 Zero reset memory
Z157-E1-01C.book Page 153 Thursday, August 31, 2006 5:13 PM
