2-4 Procedures for Through-beam Sensor
Heads
2-4-1 Positioning and Setting Threshold Values
Manual Setting
3-7-2 Inputting Threshold Values Directly
Automatic Setting
Workpiece surface positioning:
Position Teaching in 3-7-1 Teaching
Unknown size workpiece judgement:
Two-point Teaching in 3-7-1 Teaching
Judging workpiece with uneven surfaces, warped workpieces, or mov-
ing workpieces:
Automatic Teaching in 3-7-1 Teaching
2-4-2 Setting Various Functions
Changing the incident level to any value:
3-8-1 Auto-scaling
Changing the display value:
3-8-2 Scaling
Changing the response speed or increasing resolution:
3-8-3 Number of Samples to Average
Changing positioning accuracy when operating and releasing:
3-8-4 Hysteresis Setting
Holding value during measurement:
3-8-5 Hold Functions
Using OFF-delay timer:
3-8-6 Timer
Operation requiring two Sensor Heads.
3-8-7 Two-sensor Operation
Resetting default status:
3-8-8 Initializing Settings
