Reflective Sensor Heads: FUN Mode Functions Section 3-5
65
Default Settings
The settings are initialized to the default setting made at the factory. The
default settings are listed in the following table.
Refer to 4-5-8 Initializing Settings.
Mode Function Initial value
FUN Scaling values Maximum display value: Maximum
sensing distance
Minimum display value: Minimum
sensing distance
Number of samples to
average
256 samples
Hysteresis 1% of total sensing distance range
Hold Mode OFF (disabled)
Timer OFF (disabled)
Two-sensor operation
(when two Amplifier
Units are connected)
OFF (disabled)
Special selection CLOSE
Monitor focus function 4 V (20 mA): Maximum sensing dis-
tance
−4 V (4 mA): Minimum sensing dis-
tance
Intensity Mode OFF (disabled)
Differentiation function OFF (disabled)
Display reverse function OFF (disabled)
ECO display function OFF (disabled)
Limited number of dis-
play digits
All digits displayed
Settings for non-mea-
surement
KEEP
Zero reset memory
function
ON
Gain switch AUTO
T HIGH threshold Maximum sensing distance
LOW threshold Minimum sensing distance
RUN Sub-display function Threshold values
Zero reset function OFF (disabled)
Z157-E1-01C.book Page 65 Thursday, August 31, 2006 5:13 PM
