Reflective Sensor Heads: RUN Mode Functions Section 3-3
38
3-3 Reflective Sensor Heads:
RUN Mode Functions
3-3-1 Sub-display Changes
Items shown on the sub-display can be selected.
When Intensity Mode is OFF, the threshold values (HIGH/LOW), voltage
value, current value, incident level, or resolution can be selected.
When Intensity Mode is ON, the threshold values (HIGH/LOW), voltage
value, current value, or resolution can be selected.
3-3-2 Zero Reset/Release
The following are performed for the zero reset function:
• Setting the display value to 0.
• Setting the linear output to the center output value between two points
set for the monitor focus when 0 is displayed (default current output: 12
mA, default voltage output: 0 V).
The zero reset can be also released.
Refer to 4-3-4 Zero Reset Function.
• Voltage display The voltage level of the linear output is dis-
played.
• Current display The current level of the linear output is dis-
played.
• Incident level display The incident level is displayed (0 to 9999)
• Resolution display The resolution of linear output is displayed.
Display values are provided as reference values. There may be
some discrepancies in actual outputs.
The incident level displayed here is different from the one displayed
on the main display when Intensity Mode is ON.
POINT
The inclination of the linear output value against the actual distance
does not change when the zero reset is executed.
An error will occur if the zero reset is performed outside the mea-
surement range.
POINT
Z157-E1-01C.book Page 38 Thursday, August 31, 2006 5:13 PM
