149
English
8
Select [Yes] with and press
<ENTER>.
Data cloning to the display starts.
Data from USB memory
Do you copy the data ?
Yes No
The following message is displayed after data
cloning has finished.
Cloning finished. Please turn off the power.
9
After data cloning has finished,
remove the USB memory device from
the USB terminal.
10
Press the power button on the remote
control to turn the power off, and
then turn the power on. Or remove
the power plug from the outlet once,
wait for 30 seconds or more, and then
insert the power plug.
The cloned content is applied to the display.
●
When USB memory is not removed in the step 9,
the message [Select copy type] is displayed when
the display is turned on again.
Note
●
When the data is copied with [POWER button
lock] set to [On]
If the power is turned off using the power button of
the main unit in step 10, the power button of the main
unit is locked, and the power cannot be turned on
again. In this case, remove the power plug, wait for
30 seconds or more, then connect the power plug
again, and wait for a few minutes. Power indicator:
Lights up in orange (standby). Turn the power on
using the remote control, and set [POWER button
lock] to [Off]. Then, turn the power off using the power
button of the main unit, and turn the power on again.
Copying data to other display via LAN
1
Display [Setup] menu pressing
<SETUP>.
2
Select [Options] with and press
<ENTER>.
The following display appears.
Display information
Options
Software licenses
Cloning password
USB data cloning
Security password
LAN data cloning
Output log data
Shipping
3
Select [LAN data cloning] with
and press <ENTER>.
[Cloning password] screen is displayed.
4
Enter the cloning password, and then
press <ENTER>.
[LAN data cloning] screen is displayed.
5
Select [Select display] with and
press <ENTER>.
Displays on the same subnet are listed.
LAN data cloning
Select display
Execute
Write protect Off
Status Display name IP address
6
Select the display to copy the data to
with and press <VOL +>.
Select all the displays to copy the data to.
BQ1-001 192.168. 0. 1
192.168. 0. 2
192.168. 0. 4
192.168. 0. 25
192.168. 0. 31
192.168. 0. 7
192.168. 0.124
192.168. 0.211
BQ1-002
BQ1-004
BQ1-005
BQ1-014
BQ1-006
BQ1-041
BQ1-009
Select display
Please check the display to register.
Check Display name IP address
7
Press <ENTER>.
To Next Page
