Pilz PNOZmulti 2 User Manual

Servicedata
OperatingManualCommunicationinterfaces
1002971EN03
101
Profinetrecords
Devicedata Profinet
About
PNOZmulti
Configurator
Byte Record Byte
Product 0...11 43 0...11
Firmware 12...19 43 12...19
Ethernet/IPinstances
Devicedata Ethernet/IP
About
PNOZmulti
Configurator
Byte Instance Attribute Byte
Product 0...11 8 2 0...11
Firmware 12...19 8 2 12...19
8.6.4.4 Devicedataaddressing,3rdrighthandexpansionmodule
Tables
Devicedata Tables
About
PNOZmulti
Configurator
Byte Table Segment Byte
Product 0...11 91 6 0...11
Firmware 12...19 91 7 0...7
SDOs
Devicedata SDOs
About
PNOZmulti
Configurator
Byte Index Subindex
Product 0...11 0x2010 37...48
Firmware 12...19 0x2010 49...56
ModbusRegister
Devicedata ModbusRegister
About
PNOZmulti
Configurator
Byte Register Coil/DiscreteInput
Product 0...11 8264...8269 
Firmware 12...19 8270...8273 
