28
} Bit57:Reserved
4.6.4 Servicedata
TheservicedataforPROFINETisdividedintothefollowingdataareas:
} ProcessdataBaseunitandexpansionmodules
} ProcessdataFieldbusmoduleandcommunicationmodule
} Diagnosticwords
} Enableelements
} Projectdata
} Devicedata
ThecontentoftheservicedataandaddressingaredescribedinthechapterentitledSer
vicedata[ 65].
4.6.5 DiagnosticdataPNOZmESProfinet
Thesebitscontainthediagnosticdata
Unit_Diag_
Bit Content
01 STOP,baseunitisinSTOPcondition
02 BaseunitwasstoppedbytheConfigurator
03 Reserved
04 Externalerror
05 Internalerror
06 Externalerrorontheinputs
07 Internalerrorontheinputs
08 Externalerrorontheoutputs
09 Internalerrorontheoutputs
10 Noconnectiontobaseunit
11
…
21
Reserved
22 Erroronthebaseunit
23 Reserved
24 Erroronthe1stexpansionmodule,right
25 Erroronthe2ndexpansionmodule,right
26 Erroronthe3rdexpansionmodule,right
27 Erroronthe4thexpansionmodule,right
28 Faultonthe5thexpansionmodule,right
29 Faultonthe6thexpansionmodule,right
