5.6 Usabledata
Thissectiondescribesthepayloadthatcanbetransmittedastheresultofacorresponding
request.
5.6.1 Virtualinputs(InputByte0...InputByte15)
Thevirtualinputsaredefinedbythecommunicationpartnerandtransferredtothe
PNOZmulti2.Eachinputhasanumber,e.g.inputbit4ofinputbyte1hasthenumberi12.
InputByte
0 i7 i6 i5 i4 i3 i2 i1 i0
1 i15 i14 i13 i12 i11 i10 i9 i8
2 i23 i22 i21 i20 i19 i18 i17 i16
… ... ... ... ... ... ... ... ...
15 i127 i126 i125 i124 i123 i122 i121 i120
5.6.2 Watchdog
Thewatchdogisusedtomonitorthevirtualinputs.
Ifnovirtualinputsaresentbyacommunicationspartnerwithinadefinedwatchdogtime
(watchdogtimeout),thePNOZmultisetsthevirtualinputsto"0".
Theconfigurationandfunctionalityofthewatchdogvariesandsoisdescribedinthere
spectiverequests.
5.6.3 Virtualoutputs(OutputByte0...OutputByte15)
ThevirtualoutputsaredefinedinthePNOZmultiConfigurator.Eachoutputthatisusedis
givenanumberthere,e.g.o0,o5....Thestateofoutputo0isstoredinbit0ofoutputbyte
0;thestateofoutputo5isstoredinbit5ofoutputbyte0etc.
OutputByte
0 o7 o6 o5 o4 o3 o2 o1 o0
1 o15 o14 o13 o12 o11 o10 o9 o8
2 o23 o22 o21 o20 o19 o18 o17 o16
... ... ... ... ... ... ... ... ...
15 o127 o126 o125 o124 o123 o122 o121 o120
5.6.4 LEDstatus
ThestatusoftheLEDsisstoredinabyteasfollows:
} Bit0=1:LEDOFAULTislitorflashes
} Bit1=1:LEDIFAULTislitorflashes
} Bit2=1:LEDFAULTislitorflashes
} Bit3=1:LEDDIAGislitorflashes
} Bit4=1:LEDRUNislit
} Bit57:Reserved
