OperatingManualCommunicationinterfaces
1002971EN03
84
Ethernet/IPinstances
Processdata Ethernet/IP
About
PNOZmulti
Configurator
Byte Instance Attribute Byte
Inputs 0...3 3 3 0...3
Outputs 4...7 3 3 4...7
SystemLEDs 8...10 3 3 8...10
I/OLEDs 12...27 3 3 12...27
8.1.6.11 Processdataaddressing,4thlefthandexpansionmodule
Tables
Processdata Tables
About
PNOZmulti
Configurator
Byte Table Segment Byte
Inputs 0...3 22 9 0...3
Outputs 4...7 22 9 4...7
SystemLEDs 8...10 22 9 8...10
I/OLEDs 12...23 22 10 0...11
I/OLEDs 24...27 22 11 0...3
SDOs
Processdata SDOs
About
PNOZmulti
Configurator
Byte Index Subindex
Inputs 0...3 0x2008 1...4
Outputs 4...7 0x2008 5...8
SystemLEDs 8...10 0x2008 9...11
I/OLEDs 12...27 0x2008 13...28
ModbusRegister
Processdata ModbusRegister
About
PNOZmulti
Configurator
Byte Register Coil/DiscreteInput
Inputs 0...3 1402...1403 22432...22463
Outputs 4...7 1404...1405 22464...22495
SystemLEDs 8...10 1406...1407 22496...22519
