Pilz PNOZmulti 2 User Manual

Communicationmodules
OperatingManualCommunicationinterfaces
1002971EN03
46
Byte Request Byte Response
0 0x05 0 0x05
1 0x15 1 0x15
2 0x00 2 0x00
3 0x26 3 0x26
4 0x5C 4 0xDC
5 ControlByte 5 ControlByte
6 0x00 6 Reserved
7 0x00 7 0x00
8 InputByte0 8 OutputByte0
9 InputByte1 9 OutputByte1
10 InputByte2 10 OutputByte2
... ... ... ...
39 InputByte31 39 OutputByte31
40 0x00 40 Reserved
41 BCC 41 BCC
42 0x10 42 0x10
5.7.6.1 Inputdata(tothePNOZmulti)
InputByte Content
0 i7toi0
1 i15toi8
2 i23toi16
3 i31toi24
4 i39toi32
5 i47toi40
6 i55toi48
7 i63toi56
8 i71toi64
9 i79toi72
10 i87toi80
11 i95toi88
12 i103toi96
13 i111toi104
14 i119toi112
15 i127toi120
16 0x00
17 Tablenumber
