Servicedata
OperatingManualCommunicationinterfaces
1002971EN03
94
Byte AboutPNOZmultiConfigurator
... ...
11 Reserved
FieldbusspecificaddressingisdescribedinthechapterentitledProjectdata
addressing[ 95].
8.5.2 Date
Byte AboutPNOZmultiConfigurator
12 Projectcreationdate:Dayandmonth(DDMM),year(YYYY)
e.g.creationdate:28.11.2003
} Byte12:1C
} Byte13:0B
} Byte14:14
} Byte15:03
13
14
15
16 Dayandmonth(DDMM),e.g.28.11.
} Byte16:1C
} Byte17:0B
17
18 Year(JJJJ),e.g.2003
} Byte18:14
} Byte19:03
19
20 Time(HH:MM),e.g.14hours,25minutes
} Byte20:0E
} Byte21:19
21
22 Timezone1
} Byte22:0
} Byte23:1
23
FieldbusspecificaddressingisdescribedinthechapterentitledProjectdata
addressing[ 95].
8.5.3 Projectname
ProjectnamedefinedinthePNOZmultiConfiguratorunder"Enterprojectdata".Thename
isstoredinUNICODEformat(2BytescontaintheHexcodeofoneUNICODEcharacter).
Byte AboutPNOZmultiConfigurator
24 1stcharacterofprojectname
}
25
26 2ndcharacterofprojectname
}
27
... ...
...
