8.2.4 Processdataaddressing
8.2.4.1 Processdataaddressing,fieldbusmodule
Tables
Processdata Tables
About
PNOZmulti
Configurator
Byte Table Segment Byte
Inputs 0...11 23 0 0...11
Inputs 12...15 23 1 0...3
Outputs 24...35 23 2 0...11
Outputs 36...39 23 3 0...3
SystemLEDs 48...49 23 4 0...1
SDOs
Processdata Tables
About
PNOZmulti
Configurator
Byte Index Subindex
Inputs 0...15  
Outputs 24...39  
SystemLEDs 48...49 0x2009 1...2
ModbusRegister
Processdata ModbusRegister
About
PNOZmulti
Configurator
Byte Register Coil/DiscreteInput(1x)
Inputs 0...15 1456...1463 23296...23423
Outputs 24...39 1468…1475 23488...23615
SystemLEDs 48...49 1480 23680...23695
Profinetrecords
Processdata Profinet
About
PNOZmulti
Configurator
Byte Record Byte
Inputs 0...15  
Outputs 24...39  
SystemLEDs 48...49 25 0...1
