5.6.5 Tables
Furtherinformationcanberequestedintableform.
AtableconsistsofoneormorePNOZmulti2segments.Eachsegmentismadeupof13
Bytes.
Thecommunicationspartnerrequeststherequireddatausingthetablenumberandseg
mentnumber.ThePNOZmulti2repeatsthetwonumbersandsendstherequesteddata.
Thereareatotalof11tables,withthefollowingcontents:
Table20: Processdata,baseunit
Table21: Processdata,righthandexpansionmodules
Table22 Processdata,lefthandexpansionmodules
Table23: Processdata,fieldbusmodule/communicationmodule
Table70: Diagnosticwords
Table71: Enableelements
Table80: Projectinformation
Table90: Devicedata,baseunit
Table91: Devicedata,righthandexpansionmodules
Table92 Devicedata,lefthandexpansionmodules
Table93: Devicedata,fieldbusmodule/communicationmodule
ThecontentofthetablesisdescribedindetailinthechapterentitledService
data[ 65].
5.7 Requests
Arequestisdefinedviatherequestnumberandsegmentnumber.
Thefollowingrequestsareavailable:
Request
No.
Segment
No. Meaning
0x14 0x01 SendvirtualinputstothePNOZmulti2
0x14 0x02 SendvirtualinputstothePNOZmulti2,requeststateofthe
virtualoutputsandLEDstatusfromthePNOZmulti2.
0x2C 0x02 RequeststateofvirtualinputsandoutputsfromPNOZmulti2
0x2F RequestdatafromthePNOZmulti2intableform
0x5C RequestallinputandoutputdatafromthePNOZmulti2
5.7.1 Mask(MaskByte0...MaskByte15)
ThemaskisusedtodeterminewhichofthevirtualinputssentinaBytearetobeset.For
example,ifonlyinputsi0toi5aretobesetinByte8,0x3Fmustbeenteredinthemaskin
Byte24.
5.7.2 SendvirtualinputstothePNOZmulti
Request0x14Segment0x01
ThecommunicationpartnerusesthisrequesttosendvirtualinputstothePNOZmulti2.
