Servicedata
OperatingManualCommunicationinterfaces
1002971EN03
65
8 Servicedata
TheservicedataoftheconfigurablecontrolsystemPNOZmulti2isdividedintovarious
dataranges.Theservicedataisaddresseddifferently,basedonthefieldbus.
Thecontentoftheservicedataisdescribedgenerallyinthesectionsbelow.Thisisfol
lowedbythefieldbusspecificaddressing.
Dataranges:
} Processdata:Baseunitandexpansionmodules[ 66]
– Stateofinputsi0…i31[ 67]
– Stateofoutputso0…o31[ 67]
– StatusofsystemLEDs[ 67]
– StatusofIOLEDs[ 68]
} Processdata:Fieldbusandcommunicationmodule[ 85]
– Stateofvirtualinputsi0…i127[ 85]
– Stateofvirtualoutputso0…o127[ 86]
– StatusofsystemLEDs[ 87]
} Diagnosticwords[ 90]
– Diagnostics[ 90]
} Enableelements[ 92]
– ElementIDs[ 92]
} Projectdata[ 93]
– Checksums[ 93]
– Date[ 94]
– Projectname[ 94]
} Devicedata[ 96]
– Product[ 96]
– Firmware[ 97]
– Operatinghours[ 97]
