8.6.4 Devicedataaddressing
8.6.4.1 Devicedataaddressingonbaseunit
Tables
Devicedata Tables
About
PNOZmulti
Configurator
Byte Table Segment Byte
Product 0...11 90 0 0...11
Firmware 12...19 90 1 0...7
Operatinghours 24...27 90 2 0...3
SDOs
Devicedata SDOs
About
PNOZmulti
Configurator
Byte Index Subindex
Product 0...11 0x200F 1...12
Firmware 12...19 0x200F 13...20
Operatinghours 24...27 0x200F 25...28
ModbusRegister
Devicedata ModbusRegister
About
PNOZmulti
Configurator
Byte Register(3x9 Coil/DiscreteInput
Product 0...11 8192...8197 
Firmware 12...19 8198...8201 
Operatinghours 24...27 8204...8209 
Profinetrecords
Devicedata Profinet
About
PNOZmulti
Configurator
Byte Record Byte
Product 0...11 40 0...11
Firmware 12...19 40 12...19
Operatinghours 24...27 40 24...27
