Servicedata
OperatingManualCommunicationinterfaces
1002971EN03
82
ModbusRegister
Processdata ModbusRegister
About
PNOZmulti
Configurator
Byte Register Coil/DiscreteInput
Inputs 0...3 1366...1367 21856...21887
Outputs 4...7 1368...1369 21888...21919
SystemLEDs 8...10 1370...1371 21920...21943
I/OLEDs 12...27 1372...1379 21952...22079
Profinetrecords
Processdata Profinet
About
PNOZmulti
Configurator
Byte Record Byte
Inputs 0...3 20 0...3
Outputs 4...7 20 4...7
SystemLEDs 8...10 20 8...10
I/OLEDs 12...27 20 12...27
Ethernet/IPinstances
Processdata Ethernet/IP
About
PNOZmulti
Configurator
Byte Instance Attribute Byte
Inputs 0...3 3 2 0...3
Outputs 4...7 3 2 4...7
SystemLEDs 8...10 3 2 8...10
I/OLEDs 12...27 3 2 12...27
8.1.6.10 Processdataaddressing,3rdlefthandexpansionmodule
Tables
Processdata Tables
About
PNOZmulti
Configurator
Byte Table Segment Byte
Inputs 0...3 22 6 0...3
Outputs 4...7 22 6 4...7
SystemLEDs 8...10 22 6 8...10
I/OLEDs 12...23 22 7 0...11
