OperatingManualCommunicationinterfaces
1002971EN03
80
8.1.6.8 Processdataaddressing,1stlefthandexpansionmodule
Tables
Processdata Tables
About
PNOZmulti
Configurator
Byte Table Segment Byte
Inputs 0...3 22 0 0...3
Outputs 4...7 22 0 4...7
SystemLEDs 8...10 22 0 8...10
I/OLEDs 12...23 22 1 0...11
I/OLEDs 24...27 22 2 0...3
SDOs
Processdata SDOs
About
PNOZmulti
Configurator
Byte Index Subindex
Inputs 0...3 0x2007 1...4
Outputs 4...7 0x2007 5...8
SystemLEDs 8...10 0x2007 9...11
I/OLEDs 12...27 0x2007 13...28
ModbusRegister
Processdata ModbusRegister
About
PNOZmulti
Configurator
Byte Register Coil/DiscreteInput
Inputs 0...3 1348...1349 21568...21599
Outputs 4...7 1350...1351 21600...21631
SystemLEDs 8...10 1352...1353 21632...21655
I/OLEDs 12...27 1354...1361 21664...21791
Profinetrecords
Processdata Profinet
About
PNOZmulti
Configurator
Byte Record Byte
Inputs 0...3 19 0...3
Outputs 4...7 19 4...7
SystemLEDs 8...10 19 8...10
