Servicedata
OperatingManualCommunicationinterfaces
1002971EN03
95
Byte AboutPNOZmultiConfigurator
54 16thcharacterofprojectname
}
55
56 Endofcharacterstring(identifiedby"FFFF")
}
57
58 Reserved
59 Reserved
FieldbusspecificaddressingisdescribedinthechapterentitledProjectdata
addressing[ 95].
8.5.4 Projectdataaddressing
Tables
Processdata Tables
About
PNOZmulti
Configurator
Byte Table Segment Byte
Checksums 0...3 80 0 0...3
Date 12...23 80 1 0...11
Projectname 24...35 80 2 0...11
Projectname 36...47 80 3 0...11
Projectname 48...57 80 4 0...9
SDOs
Processdata SDOs
About
PNOZmulti
Configurator
Byte Index Subindex
Checksums 0...3 0x200D 13...16
Date 12...23 0x200D 25...36
Projectname 24...57 0x200D 37...70
ModbusRegister
Processdata ModbusRegister
About
PNOZmulti
Configurator
Byte Register Coil/DiscreteInput(1x)
Checksums 0...3 4096...4097 
Date 12...23 4102...4107 
Projectname 24...57 4108...4124 
