Pilz PNOZmulti 2 User Manual

Servicedata
OperatingManualCommunicationinterfaces
1002971EN03
67
8.1.1 Stateofinputsi0…i31
Byte Bit7 ... Bit0
0 i7 i6 i5 i4 i3 i2 i1 i0
1 i15 i14 i13 i12 i11 i10 i9 i8
2 i23 i22 i21 i20 i19 i18 i17 i16
3 i31 i30 i29 i28 i27 i26 i25 i24
FieldbusspecificaddressingisdescribedinthechapterentitledProcessdata
addressing[ 70].
8.1.2 Stateofoutputso0…o31
Byte Bit7 ... Bit0
4 o7 o6 o5 o4 o3 o2 o1 o0
5 o15 o14 o13 o12 o11 o10 o9 o8
6 o23 o22 o21 o20 o19 o18 o17 o16
7 o31 o30 o29 o28 o27 o26 o25 o24
FieldbusspecificaddressingisdescribedinthechapterentitledProcessdata
addressing[ 70].
8.1.3 StatusofsystemLEDs
StatusofthesystemLEDsforsupplyvoltageandbaseunitdiagnostics(seealsoAssign
mentofsystemandI/OLEDs[ 69])
Byte Bit7 ... Bit4 Bit3 ... Bit0
8 SystemLED1 SystemLED0
9 SystemLED3 SystemLED2
10 SystemLED5 SystemLED4
11 Reserved
LEDstatus 4Bitcoding
Off 0x0
On 0xF
Flashes 0x3
FieldbusspecificaddressingisdescribedinthechapterentitledProcessdata
addressing[ 70].
