Servicedata
OperatingManualCommunicationinterfaces
1002971EN03
109
Profinetrecords
Devicedata Profinet
About
PNOZmulti
Configurator
Byte Record Byte
Product 0...11 61 0...11
Firmware 12...19 61 12...19
Ethernet/IPinstances
Devicedata Ethernet/IP
About
PNOZmulti
Configurator
Byte Instance Attribute Byte
Product 0...11 9 4 0...11
Firmware 12...19 9 4 12...19
8.6.4.12 Devicedataaddressing,fieldbusmodule
Devicetypes:
} PROFIBUS:0x0001
} CANopen:0x0020
} Ethernet/IP:0x0083
} PROFINET:0x0085
} EtherCAT:0x0087
} Powerlink:0x0098
INFORMATION
Noserialnumberandnochecksumarecurrentlyenteredforthefieldbus
modules.
Tables
Devicedata Tables
About
PNOZmulti
Configurator
Byte Table Segment Byte
Product 0...11 93 0 0...11
Firmware 12...19 93 1 0...7
