Pilz PNOZmulti 2 User Manual

FieldbusModules
OperatingManualCommunicationinterfaces
1002971EN03
27
Description InputdatafromPNOZmulti2
Virtualinputsi0–i31 4InputBytes
Virtualinputsi32–i63 4InputBytes
Virtualinputsi64–i95 4InputBytes
Virtualinputsi96–i127 4InputBytes
Outputdata
TheMasterreadsthevirtualoutputsofthePNOZmulti2.
Description OutputdatafromPNOZmulti2
Virtualoutputso0–o31 4OutputBytes
Virtualoutputso32–o63 4OutputBytes
Virtualoutputso64–o95 4OutputBytes
Virtualoutputso96–o127 4OutputBytes
4.6.2 Accesstotablesegments
Thedatainthetables(seeServicedata[ 65])canberequestedviathefollowingmod
ules.
Inputdata
TheMasterrequestsatablesegmentintheform:
Description InputdatafromPNOZmulti2
Tableandsegmentnumber 2InputBytes
Outputdata
ThePNOZmulti2repliesintheform:
Description OutputdatafromPNOZmulti2
Tableandsegmentnumber+13Bytepayload 15OutputBytes
AdetaileddescriptionisavailableinthechapterentitledAccesstotablesegments[ 15].
4.6.3 LEDstatus
TheLEDstatusofthePNOZmulti2canberequesteddirectlyviathefollowingmodule.
Description OutputdatafromPNOZmulti2
LEDstatus 1OutputByte
} Bit0=1:LEDOFAULTislitorflashes
} Bit1=1:LEDIFAULTislitorflashes
} Bit2=1:LEDFAULTislitorflashes
} Bit3=1:LEDDIAGislitorflashes
} Bit4=1:LEDRUNislit
