Pilz PNOZmulti 2 User Manual

Servicedata
OperatingManualCommunicationinterfaces
1002971EN03
92
Ethernet/IPinstances
Processdata Ethernet/IP
About
PNOZmulti
Configurator
Byte Instance Attribute Byte
Diagnostics 0...23 5 1 0...23
Diagnostics 24...47 5 2 0...23
Diagnostics 48...191 5 3...8 0...23
Diagnostics 192...199 5 9 0...7
8.4 Enableelements
EachelementisassignedanIDinthePNOZmultiConfigurator.Iftheelement'soutput=0
(noenable),thecorrespondingbitisset.
Theenableelementsconsistof13Bytes.
8.4.1 ElementIDs
Byte Bit7 ... Bit0
0 ID8 ID7 ID6 ID5 ID4 ID3 ID2 ID1
1 ID16 ID15 ID14 ID13 ID12 ID11 ID10 ID9
2 ID24 ID23 ID22 ID21 ID20 ID19 ID18 ID17
3 ID32 ID31 ID30 ID29 ID28 ID27 ID26 ID25
4 ID40 ID39 ID38 ID37 ID36 ID35 ID34 ID33
5 ID48 ID47 ID46 ID45 ID44 ID43 ID42 ID41
6 ID56 ID55 ID54 ID53 ID52 ID51 ID50 ID49
7 ID64 ID63 ID62 ID61 ID60 ID59 ID58 ID57
8 ID72 ID71 ID70 ID69 ID68 ID67 ID66 ID65
9 ID80 ID79 ID78 ID77 ID76 ID75 ID74 ID73
10 ID88 ID87 ID86 ID85 ID84 ID83 ID82 ID81
11 ID96 ID95 ID94 ID93 ID92 ID91 ID90 ID89
12 Reserved ID100 ID99 ID98 ID97
8.4.2 Enableelementaddressing
Tables
Processdata Tables
About
PNOZmulti
Configurator
Byte Table Segment Byte
ID 0...12 71 0 0...12
