4.7 Wall Mount Unit: PDK-WM01
4.7.1 Specifications
External dimensions ............... 1222 mm (W) × 736 mm (H) × 131 mm (D) (48-1/8 in. (W) × 28-31/32 in. (H) × 5-5/32 in. (D))
(mounting hardware and Plasma Display <PDP-507CMX>)
1022 mm (W) × 610 mm (H) × 130 mm (D) (40-1/4 in. (W) × 24-1/32 in. (H) × 5-1/8 in. (D))
(mounting hardware and Plasma Display <PDP-427CMX>)
Weight .....................................9.3 kg (20.5 lbs.) (mounting hardware only)
44.8 kg (98.8 lbs.) (mounting hardware and Plasma Display <PDP-507CMX>)
39.8 kg (87.7 lbs.) (mounting hardware and Plasma Display <PDP-427CMX>)
Materials .................................. SPHC, SS400
Finish........................................ Semi-matte black paint on rear (Original Pioneer color)
Dimensions of packaging....... 1070 mm (W) × 100 mm (H) × 500 mm (D)
(42-1/8 in. (W) × 3-15/16 in. (H) × 19-11/16 in. (D))
Package weight....................... 11.5 kg
(25.4 lbs.)
Layers of packing .................... 30 layers
Components
Wall mount unit ................................................... × 1
Tilt adjustment metal fitting ................................ × 1
Bolts M8 .............................................................. × 6
Hexagonal wrench
(Opposite side 6 mm for M8 use) ....................... × 1
Stencil ................................................................. × 1
In wall-mounting installation allow adequate space (a clearance of 300 mm or more) above and below the panel, as well
as on the right and the left.
✩ Operating Temperature Restrictions
• Ambient temperature: 0 °C to 40 °C
✩ Operating Temperature Restrictions for Upside-Down Installations
* Upside-Down Installation is unavailable with the PDK-WM01.
✩ Operating temperature restrictions for when the speaker system (PDP-S53-LR, PDP-S56-LR) is attached.
• Ambient temperature: 0 °C to 40 °C
✩ Attachment Restrictions
• Install it on perpendicular walls, columns, etc.
It cannot be installed on an inclined surface.
Wall Mount Unit: PDK-WM01
[507CMX : 427CMX]
