[427CMX] Speaker System: PDP-S56-LR
4.12.2 External Dimensions (when mounted to the Plasma Display)
Units: mm (inch)
1204 (47-13/32)
90 (3-17/32)90 (3-17/32)
54
(2-1/8)
610 (24-1/32)
18
(23/32)
98 (3-27/32)
[Size of Plasma Display]
94
(3-11/16)
34
(1-11/32)
34
(1-11/32)
