Introduction
Introduction
The contents of “5.1 Before Beginning Adjustments (pg. 144)” and subsequent sections are premised on the PDP-
507CMX/PDP-427CMX being equipped with the PDA-5003 or PDA-5004. Items that apply only when the PDA-5003 or
PDA-5004 is installed are marked with a star ‘★’.
With the PDA-5003 or the PDA-5004 installed, the PDP-507CMX/PDP-427CMX supports the following functions:
Input/output terminals
7 PDA-5003
INPUT 1 Input • Component video signal
• RGB signals from AV devices other than PCs
INPUT 2 Input • Digital video signal (HDCP supported)
INPUT 3 Input • Y/C separate video signal
INPUT 4 Input • Composite video signal
Output • Composite video signal
INPUT 3/ Input • Audio L/R signal
INPUT 4
INPUT 5 Input • Composite video signal
• RGB signals from AV devices or PCs
• Audio L/R signal
7 PDA-5004
INPUT 1 Input • Component video signal
• RGB signals from AV devices other than PCs
INPUT 2 Input • Digital video signal (HDCP supported)
INPUT 3 Input • Y/C separate video signal
• Audio L/R signal
INPUT 4 Input • Composite video signal
• Audio L/R signal
Output • Composite video signal
INPUT 5 Input • Composite video signal
• RGB signals from AV devices or PCs
• Audio L/R signal
