Integrator Mode
11) VIDEO WALL Setting
Use this feature to configure a four panel to 25-panel video wall.
Note
This setting is adjusted when the screen size is full display.
It is not correctly displayed in other screen sizes. (See pg. 161)
Factory setting: DIVIDER .................. OFF
POSITION ............... –
TYPE ....................... NORMAL
AUTO ID .................. OFF
P.ON DELAY ........... OFF
ABL LINK ................ OFF
[Setting Method]
7 Setting the ID NO. SET
Refer to “13) Assigning an ID“ (pg. 233)
7 Setting the screen divider
1 Enter the integrator mode.
(Refer to section 5.4.1, “About the Integrator Mode” (pg. 214).)
2 Select ‘OPTION’.
3 Place the cursor on ‘VIDEO WALL’ then press the [SET]
button.
4 Place the cursor on ‘DIVIDER’.
5 Press the [2/3] buttons then press the [SET] button to
change the settings.
Each time the [2/3] buttons are pressed, the setting
changes as shown below.
OFF, 1 ..... Screen division is not performed. Set it to ‘1‘
to set an ABL link without dividing the screen.
2x2 .......... Four panel video wall
3x3 .......... Nine panel video wall
4x4 .......... 16-panel video wall
5x5 .......... 25-panel video wall
Note
• When four to 25 screens have been selected, set POSITION.
• When a problem occurs while programming the video wall settings, externally power down the video wall panels.
Screen 3
INTEGRATOR INPUT1
ENTER
SCREEN SETUP OPTIONPICTURE
SET EXIT MENU
PROGRAM T I MER
SCREEN MASK
S I DE MASK
V I DEO WAL L
BAUD RATE
I D NO. SET
:
:
:
GREEN
01H
38400BPS
Screen 4, 5
VIDEO WALL
NORMAL
OFF
OFF
:
:
:
OFF
:
SET EXIT MENU
DIVIDER
POS I T I ON
T YPE
AUTO I D
P. ON DELAY
ABL L I NK
RETURN
33 OFF 3 3 3333
2x2
3x3
1
4x4
3
33
5x5
3
