208
Menu Mode [Applicable only when a PDA-5003/PDA-5004 is installed]
17) Auto Set Up Mode Setting
This function automatically adjusts the signal when the power is turned ON, when input is changed, and when the
type of input signal is changed.
Factory setting: INACTIVE
1 Select ‘OPTION’.
2 Place the cursor on ‘AUTO SETUP MODE’ then press
the [SET] button to change the setting.
Each time the [SET] button is pressed, the setting changes
as shown below.
Note
• This setting is only effective when a PC signal is input to INPUT1 or INPUT5.
• Items one and three below are adjusted automatically.
‘SCREEN’ Adjustment inside the menu: 1. ‘POSITION’
2. ‘CLOCK’
3. ‘PHASE’
• The adjustment items are the same as when the ‘AUTO SET UP’ button is pressed on the remote control. However,
the screen may be less precise. This difference in precision is due to short processing time in the AUTO SET UP
MODE.
• It may not be possible to precisely adjust an input signal such as when the signal has low brightness. Set the
AUTO SET UP MODE to INACTIVE then adjust as explained in the following section, ‘SCREEN, CLOCK, PHASE’.
• When the AUTO SET UP MODE is set to ACTIVE and the ‘SCREEN’ is adjusted manually, ‘AUTO SETUP MODE:
ACTIVE’ is displayed.
This is to warn you that although adjustment is manual, when the input changes, or when the type of signal
changes on the outside, the AUTO SET UP MODE functions and the adjusted values are overwritten.
MENU INPUT1
CHANGE
SET
EXIT
MENU
SCREEN SETUP OPTION
LANGUAGE
ENERGY SAVE
TIMER SETTING
SCREEN MGT.
SPLIT FREEZE
AUTO SETUP MODE
AUTO FUNCTION
PIP DETECT
:STANDARD
:INACTIVE
:OFF
:ACTIVE
:ENGLISH
:OFF
Screen 2
3 INACTIVE
ACTIVE 2
To Next Page
